How to Calibrate a Smartboard

Techwalla may earn compensation through affiliate links in this story.
Image Credit: Stockbyte/Stockbyte/Getty Images

A Smartboard is a type of presentation equipment that consists of a wall-mounted or free-standing whiteboard, a projector, and a computer with Smartboard software installed. The Smartboard is an interactive device that tracks finger and pen movements on the screen. In order for the equipment to correctly track these movements, it must be calibrated. Smartboard calibration is necessary when you first set up the equipment, and after the equipment is moved or bumped into.

Advertisement

Step 1

Turn on the computer.

Video of the Day

Step 2

Locate the Smartboard pen tray at the bottom of the Smartboard screen.

Step 3

Press the Smartboard tray's "Top" and "Bottom" buttons together at the same time. This will bring up a screen with a red cross.

Step 4

Place a finger on a Smartboard pen.

Advertisement

Step 5

Press the "Yellow Square" in the middle of each red cross as it shows on the Smartboard screen. When you have finished the process, write something on the Smartboard. If the Smartboard follows your finger or pen movements, the board is calibrated correctly.

Tip

Press either the "Top" button or the "Bottom button" on the Smartboard pen tray to return to a previous point, if you are not happy with the calibration.
