How to Enter Northings & Eastings in AutoCAD

Techwalla may earn compensation through affiliate links in this story.
Northing and easting values can help drafters create blueprints from existing data.
Image Credit: Digital Vision./Photodisc/Getty Images

Northing and easting numbers represent Universal Transverse Mercator coordinates, which are horizontal and vertical positions on a global map grid. The northing value is the vertical position and the easting value is the horizontal location. This method of creating lines is often used by surveyors, who enter values to create layouts. Northing and easting values help you use known coordinates to draw maps more efficiently.


Step 1

Select the "Home" tab and choose the "Draw" panel.

Video of the Day

Step 2

Choose the "Line" drop down option. Click "Create Line By Northing/Easting." The button is marked with a line and a grid icon.

Step 3

Enter the "northing" value. Press "Enter" then type the the "easting" value.

Step 4

Type additional northing and easting values to add additional lines. Alternately, press the "ESC" key to use another method to create lines.


To switch the order of northing and easting coordinates, go to "Drawing Settings," and choose the "Ambient Settings" tab. Change the order in the "Prompt For Easting Then Northing" section.


These steps apply to AutoCAD Civil 3D 2013. The instructions may vary for different versions of the AutoCAD software.
