How to Make a Dashed Line in Microsoft Word

Techwalla may earn compensation through affiliate links in this story.
Word allows users to add lines to documents.
Image Credit: Marko Geber/DigitalVision/GettyImages

When creating a Word document, you may need to add a rule or line. In Word, the available lines include solid lines, dotted lines or dashed lines, and such lines add drama or style to a document, allowing you to emphasize information or add graphics to white space in the document. There are several ways to add a solid, dashed or dotted line in Word using options from the program's toolbar and simple key combinations. You'll also have ways to customize the line's size, color and location.


Using Shapes to Add Lines

To use the Shapes tool to add a rule or line, click the "Insert" tab, click "Shapes" in the Illustrations group, select a line, then click in the document page and drag the mouse pointer until the line is the desired length. Hold the Shift key while dragging the line to keep it straight.

Video of the Day

Length is changed by clicking on the small circle at either end of the line and dragging it to the preferred length. The "Size" commands in the Format tab of Drawing Tools at the right end of the ribbon provide an alternate method of changing the line length.


Styling Dotted Line in Word

First, add the line to the document as done in the previous step. Right-click the line, then click "Format Shape," or as an alternative, with the line selected, click the "Drawing Tools Format" tab on the Ribbon. To change the line to dashed or dotted line in Word, click the "Shape Outline" command in the Shape Styles group, then click "Dashes." Select the desired line dash type.

The Drawing Tools Format tab has commands to change the weight or boldness of the line, as well as the color of the line. Lines with arrow points can be styled with arrow end points, diamond end points or circle end points. To change line end points to circles or diamonds, or to change the size of the end points, click the "Drawing Tools Format" tab, click "Shape Outline," then click the "Arrows" command. Select the end points you prefer.


Adding Lines With Your Keyboard

To add a dark solid line to a document in Microsoft Word using the keyboard, type the "underscore" key three times, then press "Enter." For a lighter solid line, type three "hyphens," then press "Enter." Word completes the line created using this method. Other keys that create lines in this fashion are asterisks, tildes (above the Tab key), equal signs and pound signs (Shift+3).

Using Borders to Add Lines

When you need a line below a paragraph, use the Borders tool. With the mouse pointer, click in the last line of the paragraph. On the Home tab, in the Paragraph group click the "arrow" next to the Borders button. Select bottom border to add a line below the paragraph.


Using the Borders button, borders can be added to the top, bottom, left or right of the paragraph. The All Borders command encloses the entire paragraph in a border or box. The No Borders command removes all borders.
