How to Replace the CMOS in a Toshiba Satellite Laptop

Techwalla may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.
Replace the CMOS in a Toshiba Satellite Laptop

In any computer, the CMOS battery is a battery that powers a small memory chip that stores system BIOS settings. Sometimes the CMOS battery in an older laptop may need to be replaced. If the laptop asks you to set the system date and time every time you turn it on, chances are good that the battery needs to be replaced. Replacing the CMOS battery in a Toshiba Satellite model laptop is an in-depth process, but it is possible to do it yourself.

Advertisement

Step 1

Prepare the laptop for disassembly. Unplug the AC adapter and remove the battery. Remove the screw securing the DVD drive and remove the drive.

Video of the Day

Step 2

Remove the screws securing the wireless card cover, the memory card cover and the modem card cover. Remove all of the covers.

Advertisement

Step 3

Remove the wireless card and the memory modules.

Step 4

Remove the screws securing the bottom cover to the laptop and remove the bottom cover.

Step 5

This should expose the heat sink and the screws holding it to the motherboard. Remove the heat sink and any exposed screws on the bottom of the computer.

Advertisement

Step 6

Turn the laptop over and, using a guitar pick or something similar, lift the thin plastic strip running along the border of the keyboard. Depress the latches holding it to the keyboard assembly, and remove the strip.

Step 7

There are two screws holding the keyboard to the computer. Remove the screws and disconnect the keyboard cable. Remove the keyboard.

Advertisement

Step 8

This should expose several screws that hold the top cover to the base. Remove these screws, as well as the cables for the power button, touchpad and any other visible cables.

Advertisement

Step 9

Remove the top cover, exposing the motherboard.

Advertisement

Step 10

The CMOS battery, a small watch-style battery, should now be visible. Depending on the model of Toshiba, it will either be secured to the motherboard with a small battery clip, or it will be connected by two small cables. Working quickly, swap the battery for a new one. Moving quickly is necessary because in many models of computer, if the BIOS loses power for too long, it can lose all of its memorized settings, making powering on the computer a difficult, involved process.

Advertisement

Step 11

Once the battery has been replaced, follow the above steps in reverse order to assemble your laptop.

Step 12

Power on the laptop and set your system clock, if necessary.
