Photographs taken with a wide-angle lens show a slightly curved horizon.

When you take photographs of a landscape using a wide-angle lens, the horizon may appear slightly curved. The curvature increases when you use wider lenses and point the camera downward. This issue can be corrected using the "Lens Correction" filter in Photoshop, although you will need to crop the photo afterward to remove distorted edges.

Advertisement

Step 1

Launch Photoshop and open your image.

Video of the Day

Step 2

Click on the "Filter" menu, then select "Lens Correction."

Step 3

Remove the check mark from the check box labeled "Auto Scale Image" and select "Transparency" from the Edge drop-down menu underneath the check box.

Advertisement

Step 4

Press the "A" key to select the "Straighten" tool. Click on the point where the horizon meets the left edge of your image and hold the mouse button down. Drag the mouse to the point where the horizon meets the right edge of the image and let go of the mouse button. This will straighten the image.

Advertisement

Step 5

Press the "D" key to select the "Remove Distortion" tool. Select the camera make, model and lens you used to take the photo using the drop-down menus on the right. Photoshop should automatically adjust the photo to remove the horizon's curvature.

Advertisement

If the automatic adjustment does not satisfy you, click the "Custom" tab and adjust the value of the "Remove Distortion" slider until you are satisfied.

Advertisement

Step 6

Click "OK."

Step 7

Click on the "Crop" tool in the tool palette and crop the image to remove the transparent edges. Alternatively, use the "Clone," "Healing Brush" and "Patch" tools to fill in the missing areas.
