How to Use Off-Air Antenna With Direct TV

The “Off-Air Antenna” terminal located on the back of DIRECTV receivers functions as an RF pass through. Every “cable-ready” TV sold in the U.S. comes equipped with an RF input terminal. This terminal is often labeled “Antenna In” because this is the interface where the TV antenna connects. In lieu of an antenna, this interface can also be used to receive the DIRECTV satellite signal. If a DIRECTV receiver is connected to the TV’s RF input, you may also want to connect an antenna to the TV to pick up broadcast TV signals.

...

Using DIRECTV’s “Off-Air Antenna” Terminal with a Digital TV

Step

Cut power to the DIRECTV receiver before proceeding.

Step

Connect the TV antenna’s coaxial cable to the “Off-Air Antenna” terminal located on the rear panel of the DIRECTV. Oftentimes the TV antenna’s coaxial cable comes attached to the TV antenna. If this cable is not attached to the TV antenna already, connect the other end of the cable to the RF terminal located on the base of the TV antenna.

Step

Turn on the TV.

Step

Open the TV’s main “Menu” display. Go into the "Channel Setup" options and perform an automatic channel search for the antenna. The TV will conduct a scan for the broadcast TV signals available in the local area.

Using DIRECTV’s “Off-Air Antenna” Terminal with an Analog TV

Step

Cut power to the TV and DIRECTV receiver before proceeding.

Step

Connect the TV antenna’s coaxial cable to the RF “Antenna In” terminal located on the rear panel of the digital converter box. Oftentimes the TV antenna’s coaxial cable comes attached to the TV antenna. If this cable is not attached to the TV antenna already, connect the other end of the cable to the RF terminal located on the base of the TV antenna.

Step

Use another coaxial cable to connect the converter box’s RF “TV Out” terminal to the “Off-Air Antenna” terminal located on the rear panel of the DIRECTV.

Step

Plug one end of the digital converter box’s power cord into the power jack located on the back of the box. Plug the other end of the cord into a wall outlet or power strip. Turn on the TV and digital converter box. Set the TV to channel 3.

Step

Open the digital converter box’s main "Menu" display. Select “Channel Scan” from the available options. The converter box will conduct a scan for the broadcast TV signals available in the local area.
