How to Interface a Coaxial Cable Line With a Phone Line

Techwalla may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.
Phone lines carry broadband signals into DSL and IPTV homes.

Internet protocol television service connections use a variety of cable types to get the signal into the home. This is normally standard phone line, also seen in DSL broadband installations. Coaxial cable is used if the home is wired as such, preventing the need to run Ethernet cables throughout the structure. Once inside the home, coaxial cable takes over, directing the broadband signals from the router to the individual computers or network devices. Many major service providers are building this functionality, known as MoCA (Multimedia over Coax Alliance) connections, into all new products.

Advertisement

Step 1

Locate the phone line coming into the home or structure. This is commonly found in the lower-level, basement or access room.

Video of the Day

Step 2

Plug the phone line into the "Internet" port on the DSL router. Push it in until a click is heard and felt from the connector.

Advertisement

Step 3

Screw a coaxial cable from the RF connector on the DSL modem to one of the input legs on the high-bandwidth splitter.

Step 4

Locate the coaxial cable drop, normally located within close proximity of the electrical panel and/or the incoming phone line.

Advertisement

Step 5

Screw each coaxial cable into the output legs of the high-bandwidth splitter.

Advertisement

Step 6

Plug the router into AC power. Wait for the indicator lights on the front to flash green, indicating a positive connection to the incoming service.

Advertisement

Step 7

Screw the coaxial cables from the coaxial jack plates in each room to the "Broadband" or "RF" ports on each computer or networked device.
